2356100 - Water Resistant 100A Busbar with Cover

Water-resistant bussing for harsh environments. Built with wing screws for toolless access.

Features:

Accepts a wide range of wire sizes
- Includes 3 wire plugs to maintain a water-resistant rating if less than 4 wires are used
- Nests with other water-resistant 100A common busbars and ST-Blade water resistant fuse block for space-saving wiring
- Ideal for positive distribution and for the collection of negative or AC ground circuits
- Meets ABYC/USCG insulation requirements
- Tin-plated copper busses and fuse clips
- Includes four (4) write-on circuit labels
- Small format standard and custom labels are available
- Wing-screws designed for tool-free installation of cover to meet ABYC compliance

Technical Specifications:

Cover - yes
Maximum Voltage - 300V AC - 48V DC
Terminal Stud - 1 x #10-32
Continuous Rating - 100A AC or DC
Bus Material - Tin-plated Copper
Mounting Holes - Accepts 1/4" (6mm) screws
Terminal Screws - 4 x # 8-32
Wire Size - Input - (1) 8 AWG to 4 AWG
Wire Size - Load - (4) 16 AWG to 10 AWG

In the Box:

2356100 Busbar
Instruction Manual

*Sold as an Individual

Quick Guide (pdf)
